Under-cowl Panel Replacement

NOTE: Take care not to scratch the body.

1.Remove these items:


2.Remove the bolts, release the engine compartment wire harness (A) from a hook (B), then remove the under-cowl panel stay (C) and the under-cowl panel (D).




6 x 1.0 mm
9.8 N·m
(1.0 kgf·m,
7.2 lbf·ft)
CDAB

3.Install the under-cowl panel in the reverse order of removal.
