Fuel Pressure Regulator Replacement

1.Remove the fuel tank unit.

2.Remove the clips (A), and remove the fuel pressure regulator (B).




CBACA

3.Install the part in the reverse order or removal with a new O-rings (C). When installing the fuel tank unit, align the marks on the unit and the fuel tank.

NOTE: Coat the O-rings with clean engine oil.
Do not pinch the O-rings during installation.
Never apply brake fluid, vegetable oil, or alcohol-based oil to the O-rings.
