NOTE: Use the new flange bolts and new flange nut during reassembly.
10 x 1.25 mm
60 N·m
(6.1 kgf·m,
44 lbf·ft)
10 x 1.25 mm
60 N·m
(6.1 kgf·m, 44 lbf·ft)
| 1. | Raise the front of the vehicle, and support it with safety stands in the proper locations. |
| 2. | Remove the front wheels. |
| 3. | Remove the engine undercover. |
| 4. | Remove the lower arm. |
| 5. | Disconnect both stabilizer links from the stabilizer bar. |
| 6. | Remove the flange bolts (A) and the flange nut (B), then remove the front subframe stiffener plate (C). NOTE: Use the new flange bolts and new flange nut during reassembly.
10 x 1.25 mm 60 N·m (6.1 kgf·m, 44 lbf·ft) 10 x 1.25 mm 60 N·m (6.1 kgf·m, 44 lbf·ft) |
| 7. | Remove the flange bolts and the bushing holders (A), then remove the bushings (B) and the stabilizer bar (C) from the front subframe (D). NOTE: Use the new flange bolts during reassembly.
 60 N·m (6.1 kgf·m, 44 lbf·ft) |
| 8. | Install the stabilizer bar in the reverse order of removal, and nots these items:
|
